prevnext: Ra95 SMD2835 LED Strips

LED Type: CRI≥95 SMD2835
Input Voltage:DC24V
Color: Warm White, Nature White, Pure White
LED Qty: 70LED/m - 238LED/m
Beam Angle: 120 degree
IP Ratio: IP20, IP67 Version
IP67: With Silicone Tube
UL, CUL, CE, RoHS approved
Comply with the European ErP EcoDesign regulation

Inquiry Wow Customer Question

Details
Contact Us

※ Features

Features of QL Temperature Sensor Constant Current Strips:

● Constant current version: with stable current, suitable for high quality requirements project.

● DC12V/DC24V input: Can work with any DC12V/DC24V PWM control system.

● Can work with unstable power supply and without damage.

● With temperature Sensor: Can lower the current to protect itself when the temperature is too high.

● Brightness uniform: With same brightness from the first end to the last end for around 10m.

● DC24V version: can work with DC20V to DC30V Input

● DC 12V version: can work with DC10V to DC15V Input

※ Parameters

Model No.	LED	Voltage	Cutting	CRI(Ra)	PCB Width	Water proof	Color	CT:K	lumen (lm/m)	Energy efficiency class
		Power		CC/CV
QL-F2835X35SA-WW-24-95	2835 70 LED/m	DC24V 9.6W/m	100mm 7LED	≥95 CV Version	8mm	IP20 IP67	□Warm White	2700K	960-1010	F
QL-F2835X35SA-W-24-95							□Warm White	3000K	1010-1080
QL-F2835X35SA-N-24-95							□Nature White	4000K	1080-1150
QL-F2835X35SA-P-24-95							□Pure White	6000K	1080-1150
QL-F2835X70SA-W-24-95	2835 140 LED/m	DC24V 19.2W/m	50mm 7LED	≥95 CV Version	8mm	IP20 IP67	□Warm White	2700K	2000-2100	F
QL-F2835X70SA-WW-24-95							□Warm White	3000K	2100-2200
QL-F2835X70SA-N-24-95							□Nature White	4000K	2200-2300
QL-F2835X70SA-P-24-95							□Pure White	6000K	2200-2300
QL-F2835X91SA-WW-24-95	2835 182 LED/m	DC24V 18.5W/m	38.46mm 7LED	≥95 CV Version	10mm	IP20 IP67	□Warm White	2700K	1950-2050	F
QL-F2835X91SA-W-24-95							□Warm White	3000K	2050-2150
QL-F2835X91SA-N-24-95							□Nature White	4000K	2150-2250
QL-F2835X91SA-P-24-95							□Pure White	6000K	2150-2250
QL-F2835X119SA-WW-24-95	2835 238 LED/m	DC24V 24W/m	29.41mm 7LED	≥95 CV Version	10mm	IP20 IP67	□Warm White	2700K	2650-2750	F
QL-F2835X119SA-W-24-95							□Warm White	3000K	2750-2850
QL-F2835X119SA-N-24-95							□Nature White	4000K	2850-2950
QL-F2835X119SA-P-24-95							□Pure White	6000K	2850-2950
QL-F2835X63SA-WW-24-95C	2835 126 LED/m	DC24V 17W/m	55.55mm 7LED	≥95 CC Version	10mm	IP20 IP67	□Warm White	2700K	1750-1850	F
QL-F2835X63SA-W-24-95C							□Warm White	3000K	1850-1950
QL-F2835X63SA-N-24-95C							□Nature White	4000K	1950-2050
QL-F2835X63SA-P-24-95C							□Pure White	6000K	1950-2050
Remark: X is for Waterproof type. A for Non-waterproof, C for IP67
