prevnext: 180lm/W SMD2835 LED Strips

LED Type: Super Bright SMD2835
Input Voltage:DC24V
Color: Warm White, Nature White, Pure White
LED Qty:128LED/m, 64LED/m
Beam Angle: 120 degree
IP Ratio: IP20, IP67 Version
IP67: With Silicone Tube
UL, CUL, CE, RoHS approved
Comply with the European ErP EcoDesign regulation

Inquiry Wow Customer Question

※ Features

180lm/W High Efficacy LED Strips.

Features of QL Temperature Sensor Constant Current Strips:

● Constant current version: with stable current, suitable for high quality requirements project.

● DC12V/DC24V input: Can work with any DC12V/DC24V PWM control system.

● Can work with unstable power supply and without damage.

● with temperature Sensor: Can lower the current to protect itself when the temperature is too high.

● Brightness uniform: With same brightness from the first end to the last end for around 10m.

● DC24V version: can work with DC20V to DC30V Input

● DC 12V version: can work with DC10V to DC15V Input

※ Parameters

Model No.	LED	Voltage Power	Cutting	CRI	PCB Size	Water proof	Color	λ(Nm)/(CT:K)	Lumen (lm/m)	Light Efficiency
QL-F2835X64-WW-24C-HE	2835 128 LED/m	DC24V 22W/m	62.5mm 8LED	≥80	12mm	IP20/ IP67	□Warm White	2700-2900K	3300-3400	180lm/W C/D
QL-F2835X64-W-24C-HE							□Warm White	3000-3200K	3700-3800
QL-F2835X64-N-24C-HE							□Nature White	4000-4500K	3800-3900
QL-F2835X64-P-24C-HE							□Pure White	6000-6500K	3900-4000
QL-F2835X32-WW-24C-HE	2835 64 LED/m	DC24V 11.5W/m	125mm 8LED	≥80	10mm	IP20/ IP67	□Warm White	2700-2900K	1700-1800	180lm/W C/D
QL-F2835X32-W-24C-HE							□Warm White	3000-3200K	1900-1950
QL-F2835X32-N-24C-HE							□Nature White	4000-4500K	1950-2000
QL-F2835X32-P-24C-HE							□Pure White	6000-6500K	2000-2100
Remark: X is for Waterproof type. A for Non-waterproof, C for IP67
