150lm/W SMD2835 LED Strips|2835 LED Strips|

Address: 5F, BLDG A, Huilongda Ind. Zone, Shilongzai, Shiyan Town, Baoan Dist., Shenzhen, Guangdong, China

Tel: +86-755-29682086

Fax: +86-755-29682109

Skype: qlsales

prevnext: 150lm/W SMD2835 LED Strips

LED Type: Super Bright SMD2835
Input Voltage:DC24V
Color: Warm White, Nature White, Pure White
LED Qty: 224LED/m,128LED/m, 64LED/m
Beam Angle: 120 degree
IP Ratio: IP20, IP67 Version
IP67: With Silicone Tube
UL, CUL, CE, RoHS approved
Comply with the European ErP EcoDesign regulation

Inquiry Wow Customer Question

※ Features

Features of QL Temperature Sensor Constant Current Strips:

● Constant current version: with stable current, suitable for high quality requirements project.

● DC12V/DC24V input: Can work with any DC12V/DC24V PWM control system.

● Can work with unstable power supply and without damage.

● with temperature Sensor: Can lower the current to protect itself when the temperature is too high.

● Brightness uniform: With same brightness from the first end to the last end for around 10m.

● DC24V version: can work with DC20V to DC30V Input

● DC 12V version: can work with DC10V to DC15V Input

※ Parameters

Model No.	LED	Voltage Power	Cutting	CRI	PCB Size	Water proof	Color	λ(Nm)/(CT:K)	Lumen (lm/m)	Light Efficiency
QL-F2835X112WW-24C-HECES	2835 224 LED/m	DC24V 13W/m	35.71mm 8LED	≥90	12mm	IP20/ IP67	□Warm White	2700-2800K	1700-1800	150lm/W D/E
QL-F2835X112W-24C-HECES							□Warm White	3000-3200K	1800-1900
QL-F2835X112N-24C-HECES							□Nature White	4000-4200K	1900-2000
QL-F2835X112P-24C-HECES							□Pure White	6000-6500K	1900-2000
QL-F2835X64WW-24C-HECES	2835 128 LED/m	DC24V 7.5W/m	62.5mm 8LED	≥90	12mm	IP20/ IP67	□Warm White	2700-2800K	950-1000	150lm/W D/E
QL-F2835X64W-24C-HECES							□Warm White	3000-3200K	1000-1070
QL-F2835X64N-24C-HECES							□Nature White	4000-4200K	1100-1170
QL-F2835X64P-24C-HECES							□Pure White	6000-6500K	1100-1170
QL-F2835X32WW-24C-HECES	2835 64 LED/m	DC24V 3.7W/m	125mm 8LED	≥90	10mm	IP20/ IP67	□Warm White	2700-2800K	470-500	150lm/W D/E
QL-F2835X32W-24C-HECES							□Warm White	3000-3200K	500-530
QL-F2835X32N-24C-HECES							□Nature White	4000-4200K	540-570
QL-F2835X32P-24C-HECES							□Pure White	6000-6500K	540-570
Remark: X is for Waterproof type. A for Non-waterproof, C for IP67
